Electrical Data
Nominal Output Power AC (W):
6000
Nominal Power DC (W):
6000
Voltage DC to (V):
550
Voltage DC from (V):
130
Euro-Eta Efficiency (%):
94.8
Max. Input Power PV (Wp):
7500
Max. Output Power AC (VA):
6000
Max. DC Voltage (V):
550
Max. Current DC (A):
27.5
Max. Efficiency (%):
95.8
Mechanical Data & Design
Length (mm):
155
Width (mm):
430
Height (mm):
531
Item weight (kg):
30
Shipping weight (kg):
30
AC Connection:
clamp
DC Inputs (per MPPT):
3
Residual Current Protection:
yes
Fan:
no
Mains Monitoring (MSD):
MSD (ENS)
Interface Optional:
RS 485
EU Protection Class:
IP 65
Surge Protection Device DC:
thermic controlled varistors
Warranty / Certificate / Handling
Certificates
DIN VDE 0126
