SUN2000-8KTL-MAP0

SUN2000-8KTL-MAP0

SKU: 996001332
Product Condition
A - New product, in original packaging
Manufacturer
Huawei
Number of MPP Trackers
2
DC Connection
MC type 4
Lid Color
light grey
Grid Feed
3-phase
Integrated DC Circuit Breaker
mechanical DC circuit breaker
Original Packaging
yes
Interface Standard
RS 485
Transformer
no
WEEE Reg. Number
DE39372368
  • Stock status:
    Goods ordered. 192 expected on 28.02.2025.
    Stock:
    0
    Incoming:
    Goods ordered. 192 expected on 28.02.2025.
    Packing Unit:
    1 piece
  • Stock status:
    Goods ordered. 192 expected on 28.02.2025.
    Stock:
    0
    Incoming:
    Goods ordered. 192 expected on 28.02.2025.
    Packing Unit:
    1 piece
Price/Availability visible after login
We accept inquiries from commercial customers only, please login or register new with us.

Description

The HUAWEI SUN2000-5-12K-MAP0 offers top efficiency with a peak efficiency of up to 98.2%, allowing you to fully utilize the potential of your solar system and maximize your energy yields. Its flexible power range from 5kW to 12kW makes it versatile, catering to individual needs—whether for small households or larger buildings.

With the integrated FusionSolar Smart PV Management software, you have complete control over your energy production and usage at any time. Monitor and optimize your system conveniently from your smartphone or tablet.

The inverter includes comprehensive protection features such as surge protection, ground fault protection, and anti-islanding to ensure the highest safety standards. Thanks to its compact and lightweight design, the installation of the HUAWEI SUN2000-5-12K-MAP0 is quick and straightforward. The plug-and-play technology saves time and costs. With the option for storage expansion, you are well-prepared for the future, as you can store excess energy and use it when needed, which maximizes independence from the grid.

Please note that the WLAN/FE S-Dongle is not included in the package.

Electrical Data
Nominal Output Power AC (W):
8000
Voltage DC to (V):
1000
Voltage DC from (V):
160
Euro-Eta Efficiency (%):
98
Max. Output Power AC (VA):
8800
Max. DC Voltage (V):
1100
Max. Current DC (A):
16
Max. Efficiency (%):
98.6
Mechanical Data & Design
Length (mm):
490
Width (mm):
460
Height (mm):
130
Item weight (kg):
21
Shipping weight (kg):
21
DC Inputs (per MPPT):
2
Fan:
no
Mains Monitoring (MSD):
MSD (ENS)
Interface Optional:
Ethernet (LAN), WLAN
EU Protection Class:
IP 66
Surge Protection Device AC:
Type II
Surge Protection Device DC:
Type II
Warranty / Certificate / Handling
Product Warranty Manufacturer (years)
10
Certificates
CE, VDE
