Electrical Data
Nominal Power DC (W):
15000
Max. DC Voltage (V):
1000
Voltage DC from (V):
160
Voltage DC to (V):
1000
Max. Current DC (A):
20
Max. Output Power AC (VA):
15000
Nominal Output Power AC (W):
15000
Max. Efficiency (%):
98
Euro-Eta Efficiency (%):
97.2
Nominal Voltage AC (V):
400
Mechanical Data & Design
Length (mm):
540
Width (mm):
700
Height (mm):
265
Item weight (kg):
48.5
Shipping weight (kg):
52
DC Inputs (per MPPT):
1
Mains Monitoring (MSD):
MSD (ENS)
EU Protection Class:
IP 65
Warranty / Certificate / Handling
Product Warranty Manufacturer (years)
yes
Remaining Warranty (years)
5 years
Certificates
CE, CEI 0-21, DIN VDE 0126, VDE, EN 62109-1, EN 62109-2
