Electrical Data
Nominal Output Power AC (W):
100000
Voltage DC to (V):
600
Voltage DC from (V):
250
Euro-Eta Efficiency (%):
93.5
Max. Input Power PV (Wp):
110000
Max. DC Voltage (V):
650
Max. Current DC (A):
430
Max. Efficiency (%):
94.6
Mechanical Data & Design
Length (mm):
2000
Width (mm):
850
Height (mm):
2120
Item weight (kg):
1460
Shipping weight (kg):
1460
DC Inputs (per MPPT):
5
Residual Current Protection:
yes
Fan:
yes
Mains Monitoring (MSD):
MSD (ENS)
EU Protection Class:
IP 20
Surge Protection Device DC:
unknown
Warranty / Certificate / Handling
Certificates
CE, VDEW
