Electrical Data
Nominal Power (Wp):
470
Voltage at MPP (V):
34.3
Current at MPP (A):
13.71
Open Circuit Voltage (V):
40.7
Short Circuit Current (A):
14.7
Max. System Voltage IEC (V):
1500
Max. System Current (A):
25
Temp. Coefficient Pmax (%/K):
-0.29
Upper Power Tolerance (%):
3
Lower Power Tolerance (%):
Mechanical Data & Design
Length (mm):
1762
Width (mm):
1134
Height (mm):
30
Item weight (kg):
24
Shipping weight (kg):
24
Cable Length + (mm):
1200
Cable Length - (mm):
1200
Modular Construction:
glass-glass
Warranty / Certificate / Handling
Warranty Linear
yes
Performance Warranty Manufacturer (years)
30
PID Free
yes
Product Warranty Manufacturer (years)
25
Certificates
CE, IEC 61215, IEC 61730
