Electrical Data
Nominal Power (Wp):
185
Current at MPP (A):
5.1
Short Circuit Current (A):
5.4
Voltage at MPP (V):
36.28
Open Circuit Voltage (V):
43.47
Max. Reverse Current (A):
Max. System Voltage IEC (V):
1000
Max. System Voltage UL (V):
Temp. Coefficient Pmax (%/K):
-0.47
Mechanical Data & Design
Length (mm):
1580
Width (mm):
808
Height (mm):
45
Item weight (kg):
15.5
Shipping weight (kg):
15.5
Bypass Diodes:
yes
Cable Length + (mm):
900
Cable Length - (mm):
900
Max. Pressure Load (kN/m²):
Max. Pull-Off Load (kN/m²):
Modular Construction:
glass-foil
Warranty / Certificate / Handling
Performance Warranty Manufacturer (years)
10
PID Free
unknown
Product Warranty Manufacturer (years)
3
Certificates
CE, IEC 61215, UL 1703
