Electrical Data
Nominal Power (Wp):
160
Current at MPP (A):
4.58
Short Circuit Current (A):
4.97
Voltage at MPP (V):
34.9
Open Circuit Voltage (V):
43.6
Max. Reverse Current (A):
Max. System Voltage IEC (V):
1000
Max. System Voltage UL (V):
Temp. Coefficient Pmax (%/K):
-0.45
Mechanical Data & Design
Length (mm):
1595
Width (mm):
801
Height (mm):
40
Item weight (kg):
15.5
Shipping weight (kg):
15.5
Bypass Diodes:
yes
Max. Pressure Load (kN/m²):
Max. Pull-Off Load (kN/m²):
Modular Construction:
glass-foil
Warranty / Certificate / Handling
Performance Warranty Manufacturer (years)
2
PID Free
unknown
Product Warranty Manufacturer (years)
2
Certificates
CE, IEC 61215, safety class II, UL 1703
