Electrical Data
Nominal Power (Wp):
230
Voltage at MPP (V):
29.9
Current at MPP (A):
7.6
Open Circuit Voltage (V):
37.2
Short Circuit Current (A):
8.59
Max. System Voltage IEC (V):
600
Max. Reverse Current (A):
Max. System Voltage UL (V):
Temp. Coefficient Pmax (%/K):
-0.48
Mechanical Data & Design
Length (mm):
1652
Width (mm):
1000
Height (mm):
50
Item weight (kg):
20
Shipping weight (kg):
20
Cable Length + (mm):
900
Cable Length - (mm):
900
Max. Pressure Load (N/m²):
Max. Pull-Off Load (N/m²):
Modular Construction:
glass-foil
Warranty / Certificate / Handling
Performance Warranty Manufacturer (years)
5
PID Free
unknown
Product Warranty Manufacturer (years)
3
Certificates
IEC 61215, IEC 61730, UL 1703
