Electrical Data
Nominal Power (Wp):
200
Current at MPP (A):
7.19
Short Circuit Current (A):
8.2
Voltage at MPP (V):
27.8
Open Circuit Voltage (V):
36.6
Max. Reverse Current (A):
Max. System Voltage IEC (V):
870
Max. System Voltage UL (V):
Temp. Coefficient Pmax (%/K):
-0.37
Mechanical Data & Design
Length (mm):
1680
Width (mm):
990
Height (mm):
50
Item weight (kg):
24
Shipping weight (kg):
24
Bypass Diodes:
yes
Depth incl. Backrails/ Connection Box (mm):
50
Cable Cross Section (mm²):
4
Max. Pressure Load (kN/m²):
Max. Pull-Off Load (kN/m²):
Modular Construction:
glass-foil
Warranty / Certificate / Handling
Performance Warranty Manufacturer (years)
2
PID Free
unknown
Product Warranty Manufacturer (years)
2
Certificates
IEC 61215
