JAM72S30-550/MR
Description
Please notice: the modules arrive in Spain, so the transport costs have to be calculated accordingly.
Electrical Data
Nominal Power (Wp):
550
Lower Power Tolerance (W):
0
Current at MPP (A):
13.11
Short Circuit Current (A):
14
Voltage at MPP (V):
41,96
Open Circuit Voltage (V):
49.9
Max. System Voltage IEC (V):
1500
Mechanical Data & Design
Length (mm):
2279
Width (mm):
1134
Height (mm):
35
Weight (kg):
28.6
Bypass Diodes:
yes
Cable Length + (mm):
1500
Cable Length - (mm):
1500
Cable Cross Section (mm²):
4
Modular Construction:
glass-foil
Warranty / Certificate / Handling
Performance Warranty Manufacturer (years)
25
Warranty Linear
yes
PID Free
yes
Product Warranty Manufacturer (years)
12
Certificates
CE, IEC 61215, IEC 61730, safety class II, UL 1703
