Electrical Data
Nominal Power (Wp):
505
Upper Power Tolerance (%):
3
Lower Power Tolerance (%):
Current at MPP (A):
13.11
Short Circuit Current (A):
13.97
Voltage at MPP (V):
38.53
Open Circuit Voltage (V):
45.7
Max. System Voltage IEC (V):
1500
Max. System Current (A):
25
Temp. Coefficient Pmax (%/K):
-0.34
Mechanical Data & Design
Length (mm):
2093
Width (mm):
1134
Height (mm):
35
Item weight (kg):
25.3
Shipping weight (kg):
25.3
Cable Length + (mm):
1400
Cable Length - (mm):
1400
Cable Cross Section (mm²):
4
Max. Pressure Load (kN/m²):
5400
Max. Pull-Off Load (kN/m²):
2400
Modular Construction:
glass-foil
Warranty / Certificate / Handling
Performance Warranty Manufacturer (years)
25
Warranty Linear
yes
PID Free
yes
Product Warranty Manufacturer (years)
12
Certificates
CE, IEC 61215, IEC 61730, safety class II
