Electrical Data
Nominal Power (Wp):
158
Voltage at MPP (V):
23.6
Short Circuit Current (A):
7.33
Current at MPP (A):
6.68
Open Circuit Voltage (V):
30.1
Max. System Voltage IEC (V):
1000
Temp. Coefficient Pmax (%/K):
-0.478
Upper Power Tolerance (%):
5
Lower Power Tolerance (%):
Mechanical Data & Design
Length (mm):
1580
Width (mm):
800
Height (mm):
46
Item weight (kg):
15.5
Shipping weight (kg):
15.5
Bypass Diodes:
yes
Modular Construction:
glass-foil
Warranty / Certificate / Handling
Certificates
CE, IEC 61215, safety class II, UL 1703
