NA-851(WQ)

NA-851(WQ)

SKU: 2101287
Manufacturer
Sharp Europe
Cell Type
microcrystalline/amorphous
Connection Type
MC type 3
Foil Color
white
Frame Color
silver
Price/Availability visible after login
We accept inquiries from commercial customers only, please login or register new with us.
Electrical Data
Nominal Power (Wp):
85
Current at MPP (A):
1.74
Short Circuit Current (A):
2.11
Short Circuit Current (initial value) (A):
2.2
Voltage at MPP (V):
49
Open Circuit Voltage (V):
63.8
Open Circuit Voltage (initial value) (V):
65
Nominal Power (initial value) (Wp):
100
Max. Reverse Current (A):
Max. System Voltage IEC (V):
600
Max. System Voltage UL (V):
Temp. Coefficient Pmax (%/K):
-0.24
Mechanical Data & Design
Length (mm):
1129
Width (mm):
934
Height (mm):
46
Weight (kg):
18
Max. Pressure Load (kN/m²):
Max. Pull-Off Load (kN/m²):
Modular Construction:
glass-foil
Warranty / Certificate / Handling
Performance Warranty Manufacturer (years)
2
PID Free
unknown
Product Warranty Manufacturer (years)
2
Certificates
IEC 61646
