Electrical Data
Nominal Power (Wp):
395
Voltage at MPP (V):
41.07
Short Circuit Current (A):
10.35
Current at MPP (A):
9.62
Open Circuit Voltage (V):
49.45
Max. System Voltage IEC (V):
1500
Max. Reverse Current (A):
20
Temp. Coefficient Pmax (%/K):
-0.353
Upper Power Tolerance (%):
5
Lower Power Tolerance (%):
Mechanical Data & Design
Length (mm):
2008
Width (mm):
1002
Height (mm):
40
Item weight (kg):
23.5
Shipping weight (kg):
23.5
Bypass Diodes:
yes
Cable Cross Section (mm²):
4
Max. Pressure Load (N/m²):
5400
Max. Pull-Off Load (N/m²):
2400
Modular Construction:
glass-foil
Warranty / Certificate / Handling
Warranty Linear
yes
Performance Warranty Manufacturer (years)
25
PID Free
yes
Product Warranty Manufacturer (years)
15
Certificates
CE, IEC 61215, IEC 61701, IEC 61730, IEC 62716 (Ammonia Resistance), safety class II
