Electrical Data
Nominal Power (Wp):
330
Voltage at MPP (V):
37.3
Short Circuit Current (A):
9.33
Current at MPP (A):
8.85
Open Circuit Voltage (V):
45.6
Max. System Voltage IEC (V):
1000
Max. System Current (A):
15
Temp. Coefficient Pmax (%/K):
-0.39
Upper Power Tolerance (W):
Lower Power Tolerance (W):
5
Mechanical Data & Design
Length (mm):
1960
Width (mm):
992
Height (mm):
40
Item weight (kg):
22
Shipping weight (kg):
22
Cable Length + (mm):
1100
Cable Length - (mm):
1100
Cable Cross Section (mm²):
4
Max. Pressure Load (N/m²):
5400
Max. Pull-Off Load (N/m²):
2400
Modular Construction:
glass-foil
Warranty / Certificate / Handling
Warranty Linear
yes
Performance Warranty Manufacturer (years)
25
PID Free
yes
Product Warranty Manufacturer (years)
10
Certificates
CE, IEC 61215, IEC 61730
